Pipe Schedule Chart

Use our ANSI Pipe Schedule Chart to determine the nominal pipe size, wall thickness, weight and schedule designations of carbon and stainless steel pipes.

Select Nominal Pipe Size: Select Pipe Schedule:
Pipe Size OD ID Schedules Wall Est. LBS per Ft
(Steel Pipe)
1/8" .405 .307 10, 10S .049 .1863
.269 40, STD, 40S .068 .2447
.215 80, XS, 80S .095 .3145
1/4" .540 .410 10, 10S .065 .3297
.364 40, STD, 40S .088 .4248
.302 80, XS, 80S .119 .5351
3/8" .675 .545 10, 10S .065 .4235
.493 40, STD, 40S .091 .5676
.423 80, XS, 80S .126 .7388
1/2" .840 .674 10, 10S .083 .6710
.622 40, STD, 40S .109 .8510
.546 80, XS, 80S .147 1.088
.466 160 .187 1.304
.252 XX .294 1.714
3/4" 1.050 .884 10, 10S .083 .8572
.824 40, STD, 40S .113 1.131
.742 80, XS, 80S .154 1.474
.614 160 .218 1.937
.434 XX .308 2.441
1" 1.315 1.097 10, 10S .109 1.404
1.049 40, STD, 40S .133 1.679
.957 80, XS, 80S .179 2.172
.815 160 .250 2.844
.599 XX .358 3.659
1 1/4" 1.660 1.442 10, 10S .109 1.806
1.380 40, STD, 40S .140 2.273
1.278 80, XS, 80S .191 2.997
1.160 160 .250 3.765
.896 XX .382 5.214
1 1/2" 1.900 1.682 10, 10S .109 2.085
1.610 40, STD, 40S .145 2.718
1.500 80, XS, 80S .200 3.631
1.337 160 .281 4.859
1.100 XX .400 6.408
2" 2.375 2.157 10, 10S .109 2.638
2.067 40, STD, 40S .154 3.853
1.939 80, XS, 80S .218 5.022
1.687 160 .344 7.462
1.503 XX .436 9.029
2 1/2" 2.875 2.635 10, 10S .120 3.531
2.469 40, STD, 40S .203 5.793
2.323 80, XS, 80S .276 7.651
2.125 160 .375 10.01
1.771 XX .552 13.70
3" 3.500 3.260 10, 10S .120 4.332
3.068 40, STD, 40S .216 7.576
2.900 80, XS, 80S .300 10.25
2.624 160 .438 14.32
2.300 XX .600 18.58
3 1/2" 4.000 3.760 10, 10S .120 4.937
3.548 40, STD, 40S .226 9.109
3.364 80, XS, 80S .318 12.51
2.728 XX .636 22.85
4" 4.500 4.260 10, 10S .120 5.613
4.026 40, STD, 40S .237 10.790
3.826 80, XS, 80S .337 14.98
3.624 120 .438 19
3.438 160 .531 22.51
3.152 XX .674 27.54
4 1/2" 5.000 4.506 STD, 40S .247 12.54
4.290 XS, 80S .355 17.61
5" 5.563 5.295 10, 10S .134 7.770
5.047 40, STD, 40S .258 14.62
4.813 80, XS, 80S .375 20.78
4.563 120 .500 27.04
4.313 160 .625 32.96
4.063 XX .750 38.55
6" 6.625 6.357 10, 10S .134 9.290
6.065 40, STD, 40S .280 18.97
5.761 80, XS, 80S .432 28.57
5.501 120 .562 35.39
5.189 160 .719 43.35
4.897 XX .864 53.16
8" 8.625 8.329 10, 10S .148 13.40
8.125 20 .250 22.36
8.071 30 .277 24.70
7.981 40, STD, 40S .322 28.55
7.813 60 .406 35.64
7.625 80, XS, 80S .500 43.39
7.439 100 .594 50.95
7.189 120 .719 61.71
7.001 140 .812 67.76
6.813 160 .906 74.79
6.875 XX .875 72.42
10" 10.750 10.420 10, 10S .165 18.65
10.250 20 .250 28.04
10.136 30 .307 34.24
10.020 40, STD, 40S .365 40.48
9.750 60, XS, 80S .500 54.74
9.564 80 .594 64.43
9.314 100 .719 77.03
9.064 120 .844 82.29
8.750 140, XX 1.000 104.1
8.500 160 1.125 115.6
12" 12.750 12.390 10, 10S .180 24.16
12.250 20 .250 33.38
12.090 30 .330 43.77
12.000 STD, 40S .375 49.56
11.938 40 .406 53.52
11.750 XS, 80S .500 65.42
11.626 60 .562 73.15
11.376 80 .688 88.63
11.064 100 .844 107.9
10.750 120, XX 1.000 125.5
10.500 140 1.125 136.7
10.126 160 1.312 150.3
14" 14.000 13.624 10S .188 27.73
13.500 10 .250 36.71
13.375 20 .312 45.61
13.250 30, STD, 40S .375 54.57
13.124 40 .438 63.44
13.000 XS, 80S .500 72.09
12.814 60 .594 85.05
12.500 80 .750 106.1
12.124 100 .938 130.9
11.814 120 1.09 150.8
11.500 140 1.250 170.2
11.188 160 1.406 189.1
16" 16.000 15.624 10S .188 31.75
15.500 10 .250 42.05
15.375 20 .312 52.27
15.250 30, STD, 40S .375 62.58
15.000 40, XS, 80S .500 82.77
14.688 60 .656 107.5
14.314 80 .844 136.6
13.938 100 1.031 164.8
13.564 120 1.22 192.4
13.124 140 1.438 223.6
12.814 160 1.594 245.3
18" 18.000 17.624 10S .188 35.76
17.500 10 .250 47.99
17.375 20 .312 58.94
17.250 STD, 40S .375 70.59
17.124 30 .438 82.15
17.000 XS, 80S .500 93.45
16.876 40 .562 104.7
16.500 60 .750 138.2
16.126 80 .938 170.9
15.688 100 1.156 208.0
15.250 120 1.38 244.10
14.876 140 1.562 274.20
14.438 160 1.781 308.5
20" 20.000 19.564 10S .218 48.05
19.500 10 .250 52.73
19.250 20, STD, 40S .375 78.6
19.000 30, XS, 80S .500 104.10
18.812 40 .594 123.10
18.376 60 .812 155.40
17.938 80 1.031 208.90
17.438 100 1.281 256.10
17.000 120 1.500 296.40
16.500 140 1.750 341.10
16.064 160 1.969 379.20
24" 24.000 23.500 10, 10S .250 63.41
23.250 20, STD, 40S .375 96.42
23.000 XS, 80S .500 125.50
22.876 30 .562 140.70
22.626 40 .688 171.30
22.064 60 .969 238.40
21.564 80 1.219 296.80
20.938 100 1.531 357.40
20.376 120 1.812 429.40
19.876 140 2.062 483.10
19.314 160 2.344 542.10
30" 30.000 29.376 10, 10S .312 98.93
29.250 STD, 40S .375 118.65
29.000 20, XS, 80S .500 157.53
28.750 30 .625 196.06
36" 36.000 35.376 10 .312 118.92
35.250 STD, 40S .375 142.68
35.000 XS, 80S .500 189.57
34.750 30 .625 235.13
48" 48.000 47.250 STD, 40S .375 190.74
47.000 XS, 80S .500 253.65
