GripSafe®ST Pipe Reinforcement Device (PRD)
Highly Recommended for Use, Particularly on Thin-Walled Pipes. (ie., Schedule 10)
The Pipe Reinforcement Device (PRD), designed for pipe pressure testing, is a crucial tool that secures itself around the outer diameter of the pipe, effectively preventing expansion of the pipe wall during pressure testing procedures. Crafted with precision and durability, this clamp is engineered to withstand the forces generated during pressure tests, ensuring the integrity of the testing process. Its design enables a tight grip on the pipe, creating a seal that restricts outward expansion, thereby allowing for accurate pressure measurements. This device plays a pivotal role in maintaining the structural integrity of lower strength pipes with high ductility.
CUSTOMER TESTIMONIAL
"GripSafe plugs have been valuable assets on the LNGC site. The quick and easy installation, use, and removal of the plugs have made testing plain end pipe simple. The Lifting Device makes rigging of the larger plugs into position fast, convenient, and safe. The design of the grippers leave little to no marks inside the pipe. Torque values and plug info on the front plate makes plug identification and double-checking for the right plug usage easy. Overall, the GripSafe plugs are an excellent product."
T. Read / Hydro Foreman,
S. Daigle | Global EPC Company
PRD KEY BENEFITS:
- Adds strength and support to thin walled pipe, such as Schedule 10, etc.
- Can be used as a rounding tool to bring out-of-round pipe back within concentric tolerances
PRD KEY FEATURES:
- Standard safety gag feature
- Lightweight aluminum material for ease of installation
- Robust and rubbed design
- Available from 4" to 36"*
- Non-marring of pipe O.D.
*Larger sizes available upon request
Pipe Schedule Chart Link
Patents & Trademarks
Designed, Manufactured & Supplied Exclusively by USA Industries, an ISO 9001:2015 Certified Company.
- US PATENTS: 9,927,058 | 9,810,364 | D894,349 | 10,746,339 | 11,391,404 | 11,408,548 | 11,408,549
- US REGISTERED TRADEMARKS: 6,540,339 | 6,540,338 | 6,2569,105
- CANADIAN PATENT: 3,004,787 | 3,114,389 | 3,086,395 | 3,144,389
- CANADIAN INDUSTRIAL DESIGN: CA 186293
- CANADIAN TRADEMARKS: 1,168,054 | 1,168,053
- EUROPEAN PATENT: EP3377797 B1 | EP386575B1 | EP3728929B1
- EUROPEAN PATENT [Germany]: 602016051864.3
- EUROPEAN UNION DESIGN REGISTRATION: 00628264-001
- EUROPEAN UNION INTERNATIONAL TRADEMARK REGISTRATION #'s: 1567890 | 1550298 | 1550337
- AUSTRALIAN PATENT: 2016355337 | 2018392008 | 2022231742 | 2020304050
- AUSTRALIAN TRADEMARK NUMBER: 2120735
- Other US and Foreign Patents Pending
A Critical Reminder: Conducting pressure testing poses significant hazards, demanding strict adherence to safety protocols. Ensure all connections, valves, flanges, and fittings are suitable for pressure testing. Verify the compatibility of line ID & Plug Range. Most importantly, never position yourself in front of a test plug or enclosure during testing. Discharge from a plug during testing could result in severe injury or fatality.
